Suzuki DF115A/DF115SS/DF140A 2013-Present OEM Kit
Suzuki DF115A DF115SS DF140A 2013 & Up
Does not come with engine oil or gear lube
| Quantity | Price |
| 1 | 198.01 |
Suzuki OEM 4-Stroke Service Kit
Suzuki DF115A / DF115SS / DF140A 2013-Present OEM Service Kit
This OEM Suzuki service kit is built for Suzuki DF115A, DF115SS, and DF140A 2013-Present 4-stroke outboards. It includes the OEM maintenance parts commonly used for routine service, including the water pump repair kit, fuel filter element, oil filter, spark plugs, anodes, O-rings, drain gaskets, block anode gaskets, and prop nut cotter pin.
This version is the service kit without engine oil and gear lube. If you want the same service kit packaged with Suzuki 10W40 engine oil and Suzuki gear lube, see the linked kit option below.
Compatible Applications
| Make | Model | Year Range |
|---|---|---|
| Suzuki | DF115A | 2013-Present |
| Suzuki | DF115SS | 2013-Present |
| Suzuki | DF140A | 2013-Present |
Need the Kit with Oil & Gear Lube?
This 17400-92824 kit does not include engine oil or gear lube. For the same DF115A, DF115SS, and DF140A 2013-Present service package with Suzuki 10W40 engine oil and Suzuki gear lube included, use the linked kit below.
Suzuki DF115A / DF115SS / DF140A 2013-Present 10W40 Service Kit
OEM service kit option with engine oil and gear lube included.
View Kit 17400-92824-1Fluid Requirements
Engine oil is not included with this kit. This engine uses 6 quarts total of Suzuki 10W40 engine oil, which can be ordered as 1 gallon and 2 quarts. Order one Suzuki ECSTAR 10W40 gallon and two Suzuki ECSTAR 10W40 quarts.
Gear lube is not included with this kit. This engine uses 2 quarts of gear lube. Order two Suzuki ECSTAR gear lube quarts.
What is Included
| Qty | Part Number | Linked Description |
|---|---|---|
| 1 | 17400-92J21 | Water Pump Repair Kit OE Suzuki DF100 / DF115 / DF140 |
| 2 | 798 | Gasket, Gearcase Drain Suzuki DF9.9-140HP |
| 1 | 5030465 | Gasket, Oil Pan Drain Johnson/Evinrude 25-225 4 Stroke Suzuki DF25-300 |
| 1 | 0573 | Cotter Pin, Prop Nut 5pk - OEM cotter pin supplied in this OEM kit |
| 2 | 09280-22019 | O-ring, Anode Cover Suzuki DF115-DF300 |
| 4 | BKR6E | Spark Plug NGK BKR6E Suzuki 4 Stroke |
| 2 | 11265-87E10 | Gasket, Block Anode Suzuki |
| 1 | 15412-1 | Element, Fuel Filter OEM Suzuki DF140 |
| 1 | 16510-61A31 | Oil Filter Assembly Suzuki DF70-140 2006-Present |
| 4 | 55321-87J10P | Anode, Zinc Suzuki DF9-300 - OEM anodes supplied in this OEM kit |
Some customers prefer to customize their kit. Use the linked parts list above to build your own maintenance package if you need oil, gear lube, extra gaskets, or only selected OEM components.
Maintenance Value
This OEM kit groups the common Suzuki DF115A, DF115SS, and DF140A service parts into one package for annual and 100-hour maintenance planning. It is useful for water pump service, oil and gearcase drain gasket replacement, spark plug replacement, fuel and oil filter service, and anode inspection or replacement.
Key Features & Benefits
- OEM Suzuki service kit for DF115A, DF115SS, and DF140A 2013-Present outboards.
- Includes OEM water pump repair kit, filters, spark plugs, gaskets, O-rings, and anodes.
- Does not include engine oil or gear lube, making it a good option when fluids are already on hand.
- Engine requires 6 quarts of 10W40 oil: 1 gallon plus 2 quarts.
- Lower unit requires 2 quarts of Suzuki gear lube.
- Linked component table makes individual part reordering simple.
Service Kit Details
| Kit Number | 17400-92824 |
|---|---|
| Kit Type | OEM Suzuki service kit without engine oil and gear lube |
| Engine Oil Included | No - order 1 gallon and 2 quarts of Suzuki ECSTAR 10W40 separately |
| Gear Lube Included | No - order 2 quarts of Suzuki ECSTAR gear lube separately |
| Application | Suzuki DF115A, DF115SS, DF140A 2013-Present |
FAQ
Does this kit include engine oil?
No. This kit does not include engine oil. The engine uses 6 quarts total, which can be ordered as 1 gallon and 2 quarts of Suzuki ECSTAR 10W40.
Does this kit include gear lube?
No. Gear lube is sold separately with this kit. This application uses 2 quarts of Suzuki ECSTAR gear lube.
Is there a version with oil and gear lube included?
Yes. Use kit 17400-92824-1 for the OEM service kit packaged with Suzuki 10W40 engine oil and Suzuki gear lube.
Can I order the fluids separately?
Yes. Order one 10W40 gallon, two 10W40 quarts, and two gear lube quarts.
